TVS R1740
This flows 1740 cubic centimeters of air in a single rotation. If you're looking to make big power, this is ideal for 3.0 to 4.5-liter engine applications.
The key advantage of the R-Series is to deliver peak efficiencies at high pressure ratios and high speeds providing fast response and available boost when exhaust gas energy is low.
Volume per rotation
1,740 cubic centimeters
Installation
Single boosting only
Outlet design
Radial
核心功能
- 4 lobe rotor design with 160 degree twist
Learn more about TVS technology
TVS has several innovative features that make it reliable and efficient.
productfamily.specification
![]()
![]()
Key Specifications
| Performance | Unit | Value |
|---|---|---|
| Max Mass Flow Rate at PR 1.0* | kg/hr | 2,285 |
| Max Pressure Ratio | 2.5 | |
| Max Rotor Speed | rpm | 20,000 |
| Max Input Power | kW | 86 |
| Max Outlet Temperature | Celsius | 160 |
| Max Outlet Pressure | Bar | 2.5 |
| Pulley-to-rotor speed ratio | 1:1 | |
| *Standard inlet condition at 100 kPa, 25°C |
